8
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
N82 RM-313/RM-314
Page (22)
ISSUE 1
Service Manual Level 1&2
LEVEL 2 SOLDER COMPONENTS9.
N82 RM-313/ RM-314 Components overview
Solder components only for LEVEL 2
G2200
F2000
S4401
S4400
S4403
J6212
J6213
S4402
S4416
X1420
X1400
V1156
V1155
V1154
V1153
X4401
X4402
Ver. 2.0
