Nokia N93 Service Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
05.Nov.2007
11
Service Manual N93 RM-55 / RM-153 Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 7.0
MGR
Page (50)
7. Slide along the sides of the Flip C-Cover Assembly, open the
two clips as shown.
8. Remove the Flip C-Cover assembly.
9. Protect the Sub Display with a plastic lm.
10. Carefully lever up the ex connector of the display.
11. Gently unlock the snaps of the Sub Display.
12. Unscrew the four torx plus size 6 screws and remove them.

Nokia N93 Specifications

General

Zoom capability	3x
Front camera type	Single camera
Rear camera resolution	2048 x 1536 pixels
Video capture resolution (max)	640 x 480 pixels
2G standards	EDGE, GPRS
Ringer type	Polyphonic
Panel type	TFT
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	262144 colors
Internal memory	50 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	Adobe Premiere Elements 2.0
Talk time (2G)	5.1 h
Battery capacity	1100 mAh
Standby time (2G)	240 h
Product color	Black

Weight and Dimensions

Depth	28.2 mm
Width	55.5 mm
Height	118.2 mm
Weight	180 g
