Service Manual N93 RM-55 / RM-153 Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 7.0
MGR
Page (50)
31. The POP Port Bung can now be removed.
32. Use the DC Plug to remove the DC Jack.
33. Gently unlock both snaps of the Harness Holder Grip.
34. Lever it out with the SS-93.
35. Undo both Torx size 6 screws and discard them.
36. Always use new screws when reassemble.
