5
Insert the (U)SIM card and battery
A USIM card is an enhanced version of the SIM card and is
supported by UMTS mobile phones.
Always switch the device off and disconnect the charger before
removing the battery.
For availability and information on using SIM card services, contact
your SIM card vendor. This may be the service provider or other vendor.
1 With the back of the
device facing you, press
and hold the release
button, slide the cover,
and lift it up.
2 To release the (U)SIM
card holder, lift the
holder up from the handle.
3 Insert the (U)SIM card. Make sure that the contact area
on the card is facing the connectors on the device and
the bevelled corner on the card is facing the base of
the device.
4 Close the holder, and lock it into place.
5 Insert the battery. To secure the battery into place,
press it gently.
6 Replace the cover so that the locking catches are
directed towards their slots, and slide the cover
into place.
