Nokia RM-469 - Page 20

E52 RM-469, RM-481
Service Manual Level 1&2
20 CONFIDENTIAL
24
25.1
Remove the IHF SPEAKER. Remove the IHF GASKET using dental tool...
25.2
26
..and throw it away. Place the FRAME ASSY under the PWB so that the
PWB will not bend while removing the camera.
27
28
Release the CAMERA using the SS-88 Camera
removal tool.
Remove the CAMERA.
Issue 1 Copyright © 2008 NOKIA. All rights reserved.
