87
Power LED:
Lights green to indicate the unit is properly plugged into a functional AC
mains socket.
Charging LED:
Lights yellow to indicate there is a good connection to the battery and the
battery is charging.
Charged LED / Floating :
Lights green to indicate the battery is fully charged. The unit automatically
goes into Float Charge mode.
Fault / reverse polarity :
Lights red to indicate a fault or reverse polarity connection.
Negative Black Battery
Clamps
Battery Clamps Tab
Positive Red Battery
Clamps
DC Cord Storage
Compartment
PRODUCT PRESENTATION
C. Commands
Reverse Polarity/
Fault LED
Battery Charge Button
Power LED
Battery Charging LED
Charging Complete LED
AC Main Cord & Plug
and its storage
compartment
B. Product description
HF400
Charge
