Owner’s Manual 9

Operating the Refrigerator Controls

AC Operation 120 volts AC (108 volts min.-132 volts max.)

12 volts DC - control voltage (10.5 volts min. - 15.4 volts max.)

The refrigerator operates on these energy

sources. Operation out of these limits can

damage the refrigerator electrical components

and will void the warranty.

Control panel:

The refrigerator control panel (See Art01333) is

between the freezer compartment and the fresh

food compartment. To maintain the operating

control functions of the refrigerator, a 12 volt DC

power supply is necessary. The refrigerator

receives DC power from the 12 volt system of

the vehicle; either an auxillary battery, a converter, or the vehicle engine battery.

The ON / OFF button [30] starts and shuts down the refrigerator:

- To turn on the refrigerator, push and release the ON / OFF button.

- To turn off the refrigerator, push the ON / OFF button for one second and then release.

The SET TEMP button [32] controls the temperature adjustment of the freezer and the fresh food compartment.

- Push the SET TEMP button and the temperature setting (the numbers “1-9”) show in the center display [33].

- The number “9” is the coldest temperature setting.

- Push and hold the SET TEMP button and the temperature setting changes.

- Release the SET TEMP button when the temperature setting that you wish appears.

- After ten seconds, the temperature setting will go out and only a green power ON light remains.

NOTE: Push and release the MODE button [4] to show “AC”, the current mode of operation, in the center display for 10 seconds.

- If 120 volts AC is not available to the refrigerator:

- The fault codes “no” “AC” shows in the center display and an audible alarm sounds.

If 120 volts AC is available to the refrigerator, but is not operating correctly:

- A fault code shows in the center display.

- An audible alarm starts.

- Refer to the “Fault Codes” section of this manual.
