400 SERIES PARTS LIST - PAGE 6
CABINET ASSEMBLY - FRONT VIEW - 442, 443, 452, 453
NO. PART # DESCRIPTION 442 443 452 453
1 61582030 HOLE PLUG-BLACK/HINGE HOLES X X X X
2 61632930 MOUNTING CLIP-RH/WHITE/EVAPORATOR DOOR X X X X
3 619041 SPRING HOLDER ASSY-RH/EVAP DOOR/SILVER SPRING X X X X
4 61728722 CLIP-FIN XXXX
5 61580830 HINGE BRACKET-RH TOP/LH BTM/BLACK X X X X
6 61578130 HINGE PIN-BLACK/MALE X X X X
NS 61580630 HINGE PIN-BLACK/TOP/BOTTOM HINGE/FEMALE (NOT SHOWN) X X X X
7 61630422 ICE CUBE TRAY-PLASTIC X X X X
8 61578522 DOOR LATCH XXXX
9 61619930 DRIP TRAY-INSIDE X X X X
10 618054 SHELF-WIRE/TOP/FLIPPER X X
61563722 SHELF-WIRE/TOP WITH LH RISER (USE 618651) X X
618062 SHELF-WIRE/TOP/RH RISER (USE 618651) X X
NS 618065 CAP-CLEAR/FOR FLIPPER SHELF (NOT SHOWN) X X X X
11 618053 SHELF-WIRE/LOWER X X
618055 SHELF-WIRE/CUT OUT XX
NS 61580222 RETAINER-WIRE SHELF (NOT SHOWN) X X
NS 61622722 RETAINER-WIRE SHELF (NOT SHOWN) X X
12 61580322 RETAINER-GLASS SHELF XX
13 61564122 CRISPER COVER-GLASS SHELF X X
14 61571340 CRISPER-GRAY/NO BORDER OR WHEAT FIELD (USE 61571325) X X
61571325 CRISPER-WHITE XX
15 61580930 HINGE BRACKET-LH TOP/RH BTM/BLACK X X X X
16 61641822 KNOB-SELECTOR X X X X
17 61642322 KNOB-THERMOSTAT X X X X
18 61622130 FRONT COVER-BLACK/REPLACEABLE BOTTOM TRIM X X X X
19 61644022 CONTROL PANEL-BOTTOM/EG2 X X
61631122 CONTROL PANEL-BOTTOM/EG3 X X
NS 61651722 GASKET-CONTROL COVER (NOT SHOWN) X X X X
20 61631222 BRACKET-CONTROL MOUNTING/FRONT X X X X
21 619042 SPRING HOLDER ASSY-LH/EVAP DOOR/YELLOW SPRING X X X X
22 61633030 MOUNTING CLIP-LH/WHITE/EVAPORATOR DOOR X X X X
23 61620738 EVAPORATOR DOOR ASSY-WHITE/WITHOUT DECAL X X X X
NS 61618730 DOOR GASKET-EVAPORATOR/GRAY (NOT SHOWN) X X X X
NS 61579730 CAP-SNAP ON/BLACK/INSTALLATION HOLES (NOT SHOWN) X X X X
