Norcold 982 - Internal Control Information-9100 Series

Screen No.8 - 3-Way Models Only DC Heater Current
This screen displays the measured DC heater current (decimal point is implied).
A. Identifies information screen.
B. The control displays the current through the DC heater measured by the control over a range of 9 to 21 amperes. (Figure 12
indicates 16 amps).
C. Indicates BATT (DC heater) mode of operation.
To verify:
Measure DC current through the DC heater. The current will be +/- 10% of the control’s display.
Internal Control Information-9100 Series
Screen No. 1 - Input and Output
A - Identifies information screen.
1 - Not Applicable
2 - Not Applicable
3 - All modes of operation. LED on signifies the fresh
food compartment door is closed and the interior light
is off.
4 - LP GAS mode, LED on signifies a burner flame
present at the burner.
5 - AC electric mode, LED on signifies that the power
board is supplying AC voltage to power the AC heater.
6 - BATTERY mode, LED on signifies the power
board is supplying DC voltage to power the DC heater.
7 - All modes of operation, LED on signifies the
power board is supplying DC voltage to power the
moisture reduction (divider) heater.
8 - LP GAS mode, LED on signifies the power board
is supplying power to the gas valve.
9 - All modes of operation, LED on signifies the
power board is supplying DC voltage to activate the
interior light.
Screen No. 2
A
B
C
Figure 12
24
