Norcold DC0788B - Page 9

9
Ventilation
Sufcient ventilation (airow) over the rear mounted condenser of the refrigerator
is necessary for the refrigerator to operate correctly. Use any of the following
combinations of vent openings: A-D, A-I, A-J, B-C, B-F, B-H, C-D, C-I, C-J, D-F, D-H,
F-I, F-J, G-I, G-J, H-I, H-J (See Art01129 - for 0788 models only).
For the minimum required ventilation, each individual vent opening should be no less
than 50 square inches. However, the vent openings should be larger, to allow as much
ventilation as possible. The more air that circulates over the refrigerator condenser, the
more efciently the refrigerator will operate.
A
B
C
D
E
F
G
H
I
J
Art01129
