Norcold DC0788B - Installation Options

10
Do not remove the bottom
rails from the refrigerator
cabinet. The rails supply
space under the refrigerator
that is necessary for correct
ventilation.
If you do not make sure that
the ventilation is correct, a
shortened refrigerator life
expectancy, poor refrigeration,
continuous operation,
accelerated battery discharge
and a void warranty will result.
If the refrigerator is installed in an unvented enclosure,
separate the intake air and the exhaust air by a bafe.
You may construct a foam bafe from 0.5 inch foam
(See Art01982 - for R788 and F788 models only).
Installation Options
Install a decorative door panel
The decorative door panel must be 4
mm or less in thickness.
1. Remove the door from the refrigerator by removing the two (2) bolts that attach the
door hinge to the top of the refrigerator (See Art01983).
Door hinge
Bolts
Art01983
Art01982
foam baffle
0.5 inch max.
0.5 inch min.
Panel retainer
Art01985
Door panel
CAUTION
!
NOTICE
