Norcold N2152 - Maintenance and Cleaning Procedures; Cleaning Guidelines; Removing the Slide-out System; Slide-out System Removal Steps

12
1. Main PCBA cooling unit
2. Fuse 15A
3. Input power 12V DC
4. Interior Fan
5. Fan cooling unit
6. Display module
7. 2−way valve
8. Interior light
9. Interior refrigerator thermistor
10. Interior freezer thermistor
11. Ambient temperatures thermistor
12. LED module
N2152
1
2
3
12
4
5
6
11
10
9
8
7
9
