Installation and Owner’s Manual 10
Replacement Parts
You may purchase replacement parts through your local RV
dealer or authorized Norcold Service Center.
Wiring Pictorial
Wiring Diagram
The parts of the wiring pictorial are (Art01020):
1 ............................................................ 120VAC Power cord
2 ..................................................................... Terminal block
3 .......................................................................... 3 Amp fuse
4 .................................................................... Selector switch
5 ......................................................................Thermocouple
6 ............................................. Thermostat / gas safety valve
7 .................................................... Thermocouple interrupter
8 ........................................................................ Flame meter
9 ............................................................................ AC heater
10 .................... -12 VDC Power supply (3-way models only)
11 ....................+12 VDC Power supply (3-way models only)
12 .....................................20 Amp fuse (3-way models only)
16 .........................................DC heater (3-way models only)
The parts of the wiring diagram are (See Art01021):
1 .............................................................................. 120 VAC
2 .......................................................................... 3 Amp fuse
3 .......................................................................... Thermostat
4 ............................................................................ AC heater
5 .............................................................................. 120 VAC
6 .................................................................. Gas safety valve
7 .................................................... Thermocouple interrupter
8 ........................................................................ Flame meter
10 ....................................................................... Piezo lighter
11 .......................................................................... Spark gap
12 .......................................... +12 VDC (3-way models only)
13 .....................................20 Amp fuse (3-way models only)
14 .........................................DC heater (3-way models only)
15 ...................................-12 VDC Com (3-way models only)
17 .................................................................. Selector switch
6. Open the lower intake vent and put the screws through
refrigerator and into the floor.
WARNING: To avoid possible propane gas leaks,
always use two wrenches to loosen and tighten the gas
supply line at the refrigerator’s manual shut off valve.
7. Attach the gas supply line to the manual shut off valve of the
refrigerator.
8. Open the valve at the gas tank(s).
WARNING: Do not allow the leak checking solution to
touch the electrical components. Many liquids are
electrically conductive and can cause a shock
hazard,electrical shorts, and in some cases fire.
9. Examine the gas supply line for leaks.
10. Connect the DC wiring to the refrigerator:
- Install the DC fuse or connect the DC wiring to the battery or
the converter.
- Connect the DC wires from the refrigerator.
11. Connect the AC power cord to the receptacle.
To Next Page
