N61/N81 SERIES PARTS LIST - PAGE 2
UPPER DOOR (FREEZER) - N61/N81 SERIES
NO. PART # PART DESCRIPTION N610 N611 N810 N811*
1 619558 PANEL RETAINER-UPPER DOOR/BLACK/WDL (2 PER DOOR) WDL WDL
622906 PANEL RETAINER-UPPER DOOR/BROWN/WDL (2 PER DOOR) WDL WDL
623943 PANEL RETAINER-UPPER DOOR/PANEL/BLACK/SDL (2 PER DOOR) SDL SDL
624797 PANEL RETAINER-UPPER DOOR/PANEL/BROWN/SDL (2 PER DOOR) SDL SDL
2 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL WDL WDL
622924 HINGE-DOOR SIDE/TOP RH/BTM LH/BROWN/WDL WDL WDL
3 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL WDL WDL WDL WDL
4 619627 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/WDL WDL WDL
622897 DOOR LINER ASSY-UPPER/PANEL/BROWN FRAM E/WDL WDL WDL
623945 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/SDL SDL SDL
624813 DOOR LINER ASSY-UPPER/PANEL/BROWN FRAM E/SDL SDL SDL
5 618160 CAP-HINGE PLUG/BLACK ALL ALL
622989 CAP-HINGE PLUG/BROWN ALL ALL
6 621465 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/PLASTIC/BLACK ALL ALL
622916 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/PLASTIC/BROWN ALL ALL
7 622313 LATCH-STORAGE/DOOR/PLASTIC HANDLE/WARM GRAY ALL ALL ALL ALL
8 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK/WDL WDL WDL
622923 HINGE-DOOR SIDE/TOP LH/BTM RH/BROWN/WDL WDL WDL
9 618618 RAIL-UPPER DOOR/WDL (1 PER DOOR) WDL WDL WDL WDL
10 624863 BIN-DOOR SHELF/WHITE/SDL (1 PER DOOR) SDL SDL SDL SDL
NS 619569 BOLT-CAP SHOULDER/TORX HEAD ALL ALL ALL ALL
NS = NOT SHOWN
* NOTE: N811 SERIES INCLUDES N814F2 MODELS
SERIES WDL - WAFFLE DOOR LINER SDL = SMOOTH DOOR LINER
1
9
3
4
1
7
8
3
5
2
6
ART01078C
10
