3 Displays and control
BU 0540 EN-1516 33
Module Interface Data Part No. Document
Ethernet-based Bus systems
SK TU3-ECT EtherCAT Baud rate: 100 MBaud
Connector: 2 x RJ45
24V DC connection via terminal
275900180 BU 0570
and
TI 275900180
SK TU3-EIP EtherNet IP Baud rate: 100 MBaud
Connector: 2 x RJ45
24V DC connection via terminal
275900150 BU 2100
and
TI 275900150
SK TU3-PNT PROFINET IO Baud rate: 100 MBaud
Connector: 2 x RJ45
24V DC connection via terminal
275900190 BU 0590
and
TI 275900190
SK TU3-POL POWERLINK Baud rate: 100 MBaud
Connector: 2 x RJ45
24V DC connection via terminal
275900140 BU 2200
and
TI 275900140
Table 9: Overview of Technology Units and Bus Systems
Note
USS Bus modules and Modbus RTU
No optional modules are required for communication via USS or Modbus RTU.
The protocoles are integrated into all SK 5xxE series devices. An interface is available via terminal X11, or if
present, also via X7:73/74.
A detailed description of both of these protocols can be found in Manual BU 0050.
Other optional modules
Module Interface Data Part No. Document
SK EBGR-1
rectifier
Extension for direct control of an electro-
mechanical brake, IP20, snap-
mounting
19140990 TI 19140990
SK EBIOE-2 IO extension Extension with 4 DIN, 2 AIN, 2 DOUT and
1 AOUT, IP20, snap-
SK 54xE and higher
275900210 TI 275900210
Table 10: Overview of technology units, other optional modules
