NordicTrack NTEX02422-INT.2 User Manual

11
13
1
100
10
11
10. Position the wires (D, E) so that they fit neatly in
the underside of the Hand Weight Tray (38).
Orient the Tray Cover (106) so that the curved
opening (J) is in the location shown. Then, align
the Tray Cover with the Hand Weight Tray (38).
Tip: Avoid pinching the wires (D, E). Attach
the Tray Cover (106) with four M4 x 14mm
Screws (17); start all the Screws, and then
tighten them.
11. Orient the Saddle Post (13) as shown.
Loosen the indicated Post Knob (100). Next,
insert the Saddle Post (13) into the Frame (1),
and slide the Saddle Post to the desired height.
Then, tighten the Post Knob.
38
106
17
17
J
D, E
Avoid
pinching
the wires
(D, E)

NordicTrack NTEX02422-INT.2 Specifications

General

Brand	NordicTrack
Model	NTEX02422-INT.2
Category	Elliptical Trainer
Language	English
