32
HOW TO ADJUST THE DRIVE BELT
If you can feel the pedals slip while you are pedaling,
even when the resistance is adjusted to the highest
setting, the drive belt may need to be adjusted.
To adjust the drive belt, first press the power switch
and unplug the power adapter. Then, follow the
instructions below. Note: The drawings show only the
right side of the studio cycle.
Remove the indicated M4 x 14mm Screw (17) and the
Shield Cover (31) from each side of the studio cycle.
Next, loosen the M10 Axle Nut (27) on each side of
the studio cycle, and tighten the Adjustment Nut (26)
on each side of the studio cycle one half turn. Then,
firmly retighten the M10 Axle Nuts.
Plug in the power adapter, press the power switch,
and pedal the studio cycle to test the adjustment. If
necessary, repeat the above actions until the pedals no
longer slip.
When the drive belt is properly adjusted, reattach the
shield covers.
17
31
26
27
