Nordyne E2EB 017H - General; Furnace Specifications; Model Identification Code; Serial Number Identification Code

4 E2 Service Manual
MODEL IDENTIFICATION CODE
E 2 EB - 010 H - A
Electrical Code
H - 240-1-60
Product Type
E -Electric Furnace
Primary Capacity
010 - 10 kw
012 - 12 kw
015 - 15 kw
017 - 17 kw
020 - 20 kw
023 - 23 kw
Generation
2 - Second Series
Options
A -A/C Ready
Product Identifier
EH - Heat Only
EB - A/C Blower Equipped
Year
9705
01234
Month
Design Series
E
E
Manufacured Housing
Electric
2
SERIAL NUMBER IDENTIFICATION CODE
Production Code
General
E2 series electric furnaces are approved for use in
mobile/modular homes. The E2 series furnaces are
approved for downflow and upflow installations as free
standing units, or for alcove installations. All furnaces
models are approved for “zero” inch clearance from
combustible materials. For downflow alcove
installations a grille with frame may be attached to the
top of the furnace and all paneling and trim flushed to
it.
This installations provides an access door for future
installation of an air conditioning/heat pump coil. All E2
series furnaces are A/C, heat pump adaptable. Refer to
table 2 For optional air conditioner/ heat pump
equipment. The E2 series includes two models: E2EH
and E2EB models. The E2EH models are equipped
with a two speed blower and require the addition of a
replay package for the addition of air conditioning or
heat pump. The E2EB furnaces are equipped with a
multi-speed (4-speed) blower, blower relay, and cabinet
insulation.
1. Heating output rated at listed voltage. For outputs at voltages other than 240V, multiply Btuh rating by the following factors: x 0.92 (230V), x 0.84 (220V), x 0.75 (208V)
2. Height is 56" with return air grille installed, 58" with coil cabinet and 72" with coil cabinet and upflow stand.
3. The factory installed blower for the EH models can be replaced with a multi-speed blower allowing the units to accept up to 4 or 5 tons of air conditioning or heat pump.
4. The factory installed blower for the EB models can be replaced with a multi-speed blower allowing the units to accept up to 5 tons of air conditioning or heat pump.
Table 1. Unit Specifications
Electric Furnace Models E2EH E2EB
010H 012H 015H 017H 020H 023H 010H 012H 015H 017H 020H 023H
Rated Heating Output, Btuh (see note1)
35,000 41,000 53,000 57,000 70,000 75,000 35,000 41,000 53,000 57,000 70,000 75,000
Watts (Total kw, Heatin
g
Elements and
Blower) 10.4 12.0 15.4 16.6 20.4 22.0 10.4 12.0 15.4 16.6 20.4 22.0
Supply Voltage 240/208 Volts/60Hz/1-Phase
Heating Elements, No.(Total kw) 2 (10.0) 2 (11.6) 3 (15.0) 3 (16.2) 4 (20.0) 4 (21.6) 2 (10.0) 2 (11.6) 3 (15.0) 3 (16.2) 4 (20.0) 4 (21.6)
Blower: Wheel Size 10.5" Dia., 8" Wide 10.5" Dia., 8" Wide
Motor Speeds, H.P. Rating, Amps 2 Speed, 1/5 Hp, 2.0 Amps 4 Speed, 1/3 Hp, 2.9 Amps
Test ESP, in. w.c. Max 0.3
Optional Coolin
g
Available with factory
installed blower
2.0 - 3.0 ton (see note 3) 2.0 - 4.0 ton (see note 4)
Optional Heat Pump Available with
factory installed blower
2.0 - 3.0 ton (see note 3) n/a (see note 3) 2.0 - 4.0 ton (see note 4)
Air Filter (Standard) 16" x 20" x 1" (nominal)
Furnace Dimensions Width - 20" (508 mm) Height - 29" (737 mm) ( see note 2) Depth - 24-1/2" (623 mm)
