20
DO NOT USE GASOLINE, CRANKCASE OIL,
OR ANY OIL CONTAINING GASOLINE.
WARNING:
Failure to keep supply of oil clean
by various procedures described
above may cause failure of certain
components such as the fuel pump
gears, check valve, shaft seal, or
burner nozzle which may result in a
burner fi re.
15. FLUE GAS SAMPLING
It may be necessary to take fl ue gas sampling
from oil and gas gun furnaces (M1S and M1B
Series Models) in order to check the performance
after furnace installation. A fl ue gas sample
may be taken from the heat exchanger, which
is located behind the hole of the top-front of
blower compartment.
1. STOP! Read the SAFETY INFORMATION.
2. Turn off all electric power to the appliance.
3. Remove the black plastic cap located above
the blower and save.
4. Through the top of the blower compartment
hole, drill a hole for your sampling tube into
the heat exchanger.
5. Insert sampling tube through the drilled
hole.
6. After a complete check and adjustment of
furnace performance, fi ll the drilled hole with
a screw that is larger than the hole.
7. Put silicon sealant (rated at least 500° F)
around the screw.
8. Plug the outside hole with the plastic cap you
removed in step 3.
WARNING:
If you do not follow these instructions
exactly, a fi re or explosion may result
causing personal injury, loss of life, or
property damage.
16. LIGHTING AND SHUTDOWN
GENERAL-ALL MODELS
Read the safety information on the front page
of these installation instructions before lighting
furnace. DO NOT ATTEMPT TO LIGHT FUR-
NACE IF YOU SMELL GAS.
SAFETY INFORMATION
FOR YOUR SAFETY READ BEFORE LIGHT-
ING.
a. The fi rst lighting of the furnace after any
home setup must be performed by a quali-
fi ed service technician.
b. If this appliance has a pilot that must be lit by
hand, follow these instructions exactly.
c. BEFORE LIGHTING smell all around the
furnace for gas. Be sure to smell next to the
fl oor because some gas is heavier than air
and will settle on the fl oor.
d. WHAT TO DO IF YOU SMELL GAS: Do not
try to light any appliance. Do not touch any
electric switch and do not use any phone in
your building. Immediately call your gas sup-
plier from a neighbor’s phone. Follow the gas
supplier’s instructions. If you cannot reach
your gas supplier, call the fi re department.
e. Use only your hand to push in the gas control
lever. Never use tools. If the lever will not push
in by hand, don’t try to repair it. Call a qualifi ed
service technician. Force or attempted repair
may result in a fi re or explosion.
f. Do not use this furnace if any part has been
under water. Immediately call a qualifi ed
service technician to inspect the furnace and
to replace any part of the gas valve or control
system which has been under water.
LIGHTING INSTRUCTIONS FOR STANDING
PILOT MODELS.
a. Stop! Read the safety information.
b. Set the thermostat to the lowest setting.
c. Turn off all electric power to the appliance.
d. Push in the gas control lever slightly and move
left to “OFF.” DO NOT FORCE.
e. Wait ten (10) minutes to clear out any gas.
If you then smell gas, STOP! Follow step “d”
in the SAFETY INFORMATION. If you don’t
smell gas, go to the next step.
f. Find pilot - follow metal tube (pilot tube) from
gas control valve. Open hinged fi re observa-
tion door. The pilot is found at the end of the
pilot tube just left of the pilot shield.
g. Slightly depress the gas control lever and
move it right to the “ON” position and release;
then move it to the “PILOT” position.
h. Move the control lever to “SET” and hold. Im-
mediately light the pilot with a match. Continue
to hold the control lever for about one (1)
minute after the pilot is lit. Release the lever
and it will spring back to the “PILOT” position.
Pilot should remain lit. If it goes out, repeat
