Nordyne MB7BM Series User Manual

27
CONTROL SIGNAL & MODE OPERATION TOTAL KW BOARD ACTION
W
EHEAT
On
5 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
10 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
15 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 10 seconds delay
20 KW
Stage 1 Heat on instantly
Heat blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 10 seconds delay
Stage 4 Heat on after 15 seconds delay
Off
Heat stages off instantly
Blower off after 15 second delay
W & Y
AUX HEAT
On
5 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
10 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
15 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 10 seconds delay
20 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 10 seconds delay
Stage 4 Heat on after 15 seconds delay
Off
Heat stages off instantly
Heat blower turns off after 40 second delay
G
FAN
On Cool blower on after 3 second delay
Off Cool blower off instantly
Y HEAT PUMP
& COOL
On Cool Blower on after 3 second delay
Off Cool Blower off after 40 second delay
Table 10. Heating Element Logic for MB7BM Air Handlers
