NORIS Automation GmbH, Friedrich-Barnewitz-Str. 10, D -18119 Rostock
phone: +49 381 519944-0, fax: +49 381 519944-4, info@noris-automation.de
SG2000
User Manual
NAR-KD-0151-1-en
V. 1.01 - 04/07/16
page 5 of 9
3 Principal scheme
Fig. 1 principal scheme
CAUTION
The current sense for the solenoids is behind
terminal 9 and 10, this connection is to be
separated always.
In case of solenoid systems with 3- pole
connection, use as common terminal 11 or 12
(+24V supply)
