Nortek Security & Control Mighty Mule MM371W User Manual

Copyright
©
2019 Nortek Security and Control, LLC. 10022114 A
Mighty Mule
®
is the retail brand of Nortek Security and Control, LLC.
This product meets the requirements of UL325 7th Edition, the standard for gate operator safety.
Installation Manual
(For a single or dual gate installation)
Horizontal Support
Gate Swings Evenly and Freely
Hung Firmly and Plumb
Post Bracket
Control Box
Fence Post Set in Concrete Fence Post Set in Concrete
Run 1000' (max.) of low
voltage wire to control
box from transformer
(wire not included).
Power Cable
PVC conduit (not included)
to protect wire from lawn
mowers and weed eaters.
PVC conduit (not included)
to run second opener power
cable under driveway.
Gate Bracket
Warning Sign
Secondary Opener
Primary Gate Opener
Horizontal Support
Post Bracket
Gate Bracket
Warning Sign
120 Volt indoor
Transformer
(surge protector
not supplied)
12 Volt automotive or marine
type battery in weather proof
housing (not included).
Example of Dual Gate nished installation
(Installations vary slightly on different types of gates)
MM371W
MM372W
Single gate installation [MM371W]
Dual gate installation MM372W]

Nortek Security & Control Mighty Mule MM371W Specifications

General

Type	Swing Gate Opener
Operating Voltage	12 VDC
Max Gate Length	16 ft
Battery Backup	Yes
Weather Resistant	Yes
Smart Control	No
Solar Panel	Optional
Remote Control	Yes
Number of Remotes	2
Power Source	AC or Solar
Control Type	Remote Control
Opening Speed	12 seconds
Battery Type	12V Lead Acid
