Figure 5. Coil Dimensions
W
HS
HL
H
5/8
4
17 3/4
20 3/4
FRONT VIEW
TOP VIEW
Distributor
Thermal Expansion
Valve (TXV)
Door
TXV
Retaining
Nut
Liquid Line
Stub w/ Screen
Accessory
Retaining Nut
Grommet
Figure 6. TXV Assembly
