Page #4 background imageLoading...
Page #4 background image
BayStack 420-24T Switch Product Brief4
Technical Specifications
Table 1: BayStack 420-24T Technical Specifications.
Performance Specifications (64-byte packets)
Maximum Forwarding Rate 5.1 Mpps
Switched 10 Mbps forwarding rate 14,880 pps
Switched 100 Mbps forwarding rate 148,810 pps
Switched 1000 Mbps forwarding rate 1,488,100 pps
Latency 100 Mbps ports 3 usec
Latency 1000 Mbps ports 2 usec
Network Protocol and Standards Compatibility IEEE 802.3 CSMA/CD (ISO/IEC 8802-3)
IEEE 802.3 10BASE-T (ISO/IEC 8802-3, Clause 14)
IEEE 802.3u 100BASE-TX (ISO/IEC 8802-3, Clause 25)
IEEE 802.3u Autonegotiation on Twisted Pair (ISO/IEC 8802-3, Clause 28)
IEEE 802.3x (Flow Control on the Gigabit Uplink port)
IEEE 802.3z (Gigabit)
IEEE 802.1D MAC Bridges (ISO/IEC 10038)
IEEE 802.1Q (VLAN Tagging)
Data Rate and Encoding
10 Mbps Manchester encoding
100 Mbps 4B/5B encoding
1000 Mbps 8B/10B
Electrical Specifications
Line Frequency 47-63 Hz
Input Volt Ampere Rating 65 VA maximum
Input Power 50 W maximum
Input Voltage 100-240 VAC
Input Current 2 A @ 100, 1 A @ 240
Thermal Rating 220 Btu/hr
Physical Dimensions
Height 1.75 in (4.45 cm) – 1U High
Width 17.125 in (43.5 cm)
Depth 8.0 in (20.32 cm)
Weight 6.2 lb (2.83 kg)
