Office Alarm System Version 2 3-7
DMS-100 Family Alarm System Description Reference Manual BASE12
distribution cards. The NT3X82 cards contain all the required control
relays.
Version 2 OAS equipment combinations
Table 3-2 shows equipment combination examples for a remote line module
(RLM), a small DMS-100 Family office, and a large DMS-100 Family
office.
Table 3-2
Examples of Version 2 OAS equipment combinations
System
requirements
Alarm system
for RLM
Alarm system
for small office
Complete alarm system for large
office
Equipment
located in OAU
shelf
NT2X57AA,
NT0X10AA
NT3X82AB,
NT2X57AA,
NT0X10AA
NT3X82AA,
NT3X83AA or NT3X84AA,
NT3X85AA
NT3X84AA NT2X57AA (2)
NT0X10AA (6)
Equipment
located in
standby MTM
none NT3X82AB NT3X82AA
Related
equipment
NT0X63AC NT0X63AC NT3X89AA,
NT0X63AA
NT0X63AB,
NT0X64AA (2),
NT0X66AA (2),
NT0X61AB
Related
illustration in
this NTP
none Figure 3-1 Figure 3-2
Note:
Numbers in parentheses indicate quantities required, if other than one.
