Appendix A: Data communications planning 10-75
Planning Guide NT6Q92MA Rel 1.0 Iss 1 Standard September 2006
DCN example 10 - Using single OME6500 GNE with iISIS to reach remote
OME6130 network elements in a SNCP ring configuration with generic
SDH equipment.
In this example (see Figure 10-21 on page 10-76, Figure 10-22 on page 10-77
and Figure 10-23 on page 10-78), a single OME6500 network element is used
as the GNE to establish communication between the external DCN and the
OME6130 within a SNCP ring with generic SDH equipment (such as OM4000
and TN-1C network elements).
iISIS routing protocol is used with auto-tunneling to establish communication
from the OME6500 GNE to the remote OME6130 network elements.
The remote OME6130 NEs are provisioned as proxy ARP neighbours at the
OME6500 GNE.
DCN provisioning details
Table 10-27 on page 10-79 and Table 10-28 on page 10-80 detail the DCN
parameters for the DCN example 10 configuration.
Note: For parameters not listed, use the default settings.
