Northern Lights LX-E - Specifications; Generator Specifi Cations

OLXE 03/10
12
Generator Specifi cations: Taiyo Winding Resistances for LX-E 34E
All ratings in Ohms @ 20° C
1 or 3 Phase
MAIN
STATOR: 0.0580 Ω
1 or 3 Phase
MAIN
ROTOR: 3.3 Ω
1 or 3 Phase
EXCITER
STATOR: 16.4 Ω
1 or 3 Phase
EXCITER
ROTOR: 0.629 Ω
1 or 3 Phase
AUXILIARY WINDING: 1.34 Ω
1 Phase 3 Phase
FULL LOAD 50 Hz/ 220 volts 21.2 volts
EXCITATION 60 Hz/ 240 volts 19.0 volts
VOLTAGE: 50 Hz/ 220 volts 31.3 volts
50 Hz/ 400 volts 29.0 volts
60 Hz/ 208 volts 24.6 volts
60 Hz/ 480 volts 27.0 volts
