Northern Lights LX-E - Page 16

OLXE 03/10
16
Junction Box (Single Phase Wiring Shown)
Key Description Part Number
1 Grommet NG-79-R
2 Circuit Breaker 22-40018
3 Terminal 22-45413
4 Automatic Voltage Regulator (DST-100-2FAK) 22-42071
5 Terminal UK150-3J
6 Circuit Breaker 3 Amp 22-42077
7 Rubber Mount 33-40007
8 Bracket, Junction Box Mtg. - Right and left 3T303-672
9 Junction Box 3T303-671
10 Relay Board Sub-Assembly 22-70083-1 Manual Start
Relay Board Sub-Assembly 22-70086-1 Autostart
11 Relay 12 Volt (4 ea.) 22-42047
Relay 24 Volt (4 ea.) 22-40085
12 Timer Module 12 Volt 22-40407
Timer Module 24 Volt 22-40408
3T102-430-2
