IP4BIR100 IP Bullet Camera · Quick Start Guide
15
15
No.
Components
4
Waterproof Endcap
5
Waterproof Rubber Gasket
6
Lock Nut
7
Network Cable from Router/Switch
Camera
Switch/Router
Align the snap and notch.
i. Insert ⑤ into ④.
ii. Secure ⑥ with ④.
Water-proof Accessory Installation Figure 2-7
Steps:
