IP4DIR100 Series IP Dome Camera · Quick Start Guide
24
24
Install the Bubble Figure 2-16
2.4 Network Cable Waterproof Jacket
Installation
Purpose:
If the camera is installed outdoor, you should use the waterproof
accessory for the network cable after the camera is secured on the
installation surface.
①
②
③
④
⑤
⑥ ⑦
Figure 2-17 Waterproof Accessory Components
