Item 114656 (804315) – e420 Engine Parts Explosion – Rev A.4
37
REF#
PART #
DESCRIPTION
QTY
1
Kit #1, Kit #8
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
5
2
Kit #8
COVER SUBASSEMBLY, CYLINDER HEAD
1
3
Kit #4, Kit #8
CYLINDER HEAD COVER GASKET
1
4
Kit #4, Kit #8
GASKET, BREATH GROOVE
1
5
Kit #8
STOP ENGINE PIECE SUBASSEMBLY
1
6
Kit #6, Kit #7,
Kit #8, Kit #20
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
11
7
Kit #7
SHAFT SUBASSEMBLY， ROCKER
2
8
Kit #7
ROCKER SUBASSEMBLY, VALVE
2
9
Kit #7
CYLINDER HEAD COVER PIN LIMIT PLATE
1
10
Kit #7
R0TATOR, VALVE
2
11
Kit #7
CLAMP, VALVE LOCK
4
12
Kit #7
SEAT, VALVE SPRING
2
13
Kit #7
SPRING, VALVE
2
14
Kit #7
GUIDE, SEAL
1
15
Kit #7
VALVES SET
1
16
Kit #9
CYLINDER HEAD BOLT
4
17
Kit #9
HEAD SUBASSEMBLY, CYLINDER
1
18
Kit #9
SHROUD, CYLINDER BODY
1
19
805750 or Kit #9
SENSOR, TEMPERATURE
1
20
Kit #9
BUSH
1
21
Kit #4, Kit #9
GASKET, CYLINDER HEAD
1
22
Kit #9
POSITION PIN - TYPE A
2
23
805572
RING ASSY, PISTON
1
24
805573
CLIP, PISTON PIN
2
25
805574
PIN, PISTON
1
26
805575
PISTON
1
27
805576
ROD, CONNECTING
1
28
Kit #9
STUD BOLT (BM=2D)
2
29
Kit #4, Kit #5
GASKET, INLET
1
30
Kit #5
PLATE, CARBURETOR INSULATOR
1
31
Kit #4, Kit #5
CARBURETOR SEAL GASKET
1
32
805619
ECU ASSEMBLY
1
33
Kit #4, Kit #5
AIR CLEANER SEAL GASKET
1
34
Kit #1
PIPE CLAMP
2
35
Kit #1
TUBE, BREATHER
1
36
Kit #1
KNOB
1
37
Kit #1
COVER, AIR CLEANER CASE
1
38
Kit #1
BUTTERFLY NUT - STAMPED
1
39
Kit #1, Kit #10
AIR CLEANER ELEMENT ASSEMBLY
1
40
Kit #1
AIR CLEANER BASE BODY
1
41
Kit #1
HEXAGON NUT WITH FLANGE
2
42
Kit #24
FLAT WASHER
2
43
Kit #24
BOLT, DRAIN PLUG
2
44
805620
CRANKCASE SUBASSEMBLY.
1
45
805578
SEAL, OIL
1
46
805570
PLUG, RUBBER
1
47
805621 or Kit #23
COIL SUBASSEMBLY, CHARGE
1
48
Kit #23
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
2
