NorthStar e300 - Page 38

Item 114656 (804315) – e420 Engine Parts Explosion – Rev A.4
38
49
Kit #23
CLAMP, CHARGE COIL
1
50
Kit #23
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
1
51
805622
FLYWHEEL SUBASSEMBLY
1
52
Kit #22
IMPELLER
1
53
Kit #22
PULLEY, STARTER
1
54
Kit #22
NUT, FLYWHEEL
1
55
805762
WIRE CLIP
1
56
Kit #6, Kit #19
BAND
3
57
Kit #6
WIRE CLIP
1
58
Kit #6
SHROUD
1
59
Kit #6
STARTER ASSY, RECOIL
1
60
Kit #6
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
3
61
805571
LED LOGO
1
62
Kit #12
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
2
63
805582 or Kit #12
COIL, IGNITION
1
64
N/A
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
2
65
805623
STARTING MOTOR ASSEMBLY
1
66
805579
CRANKSHAFT ASSY.
1
67
805580
DEEP GROOVE BALL BEARING - P53
2
68
805581
SHAFT ASSY, BALANCING
1
69
Kit #7
CAMSHAFT ASSY.
1
70
Kit #7
TAPPET, VALVE
2
71
Kit #7
LIFTER SUBASSEMBLY, VALVE
2
72
Kit #11
HEXAGON NUT WITH FLANGE
1
73
Kit #11
SENSOR, ENGINE OIL
1
74
Kit #11, Kit #25
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
75
Kit #4, Kit #21
GASKET, CRANKCASE
1
76
Kit #21
POSITION PIN - TYPE A
2
77
Kit #21
DEEP GROOVE BALL BEARING - P53
1
78
Kit #21
COVER, CRANKCASE
1
79
805467 or Kit #21
DIPSTICK SUBASSEMBLY, OIL
2
80
Kit #21
SEAL, OIL
1
81
Kit #21
HEXAGON SOCKET FLANGE FACE BOLT - SMALL SERIES
7
82
Kit #9, Kit #10
PLUG, SPARK
1
83
Kit #9
STUD BOLT (BM=2D)
2
84
Kit #2, Kit #4
GASKET, EXHAUST OUTLET
1
85
Kit #2
MOUNTING BRACKET
1
86
Kit #2
MUFFLER
1
87
Kit #2
LOCK NUT
5
88
Kit #3
CROSS-RECESSED SELF-TAPPING SCREW
4
89
Kit #3
COLLECTOR, SPARK
1
90
Kit #2, Kit# 4
GASKET, MUFFLER
1
91
Kit #2
PIPE, EXHAUST
1
93
Kit #18
COVER, FUEL TANK
1
94
Kit #18
SLEEVE, FILLING OIL HOLE RUBBER
1
95
Kit #10, Kit #18
STRAINER，FUEL
1
96
Kit #14
COPING, ENGINE COUTER COVER
1
97
Kit #17
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
98
Kit #17
FUEL TANK
1
99
Kit #13
FRAME， FUEL TANK INSTALLTION
1
