NorthStar e300 - Page 39

Item 114656 (804315) – e420 Engine Parts Explosion – Rev A.4
39
100
Kit #13
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
101
Kit #14
HEXAGON SOCKET FLANGE FACE BOLT - SMALL SERIES
4
102
Kit #14
HOUSING, ENGINE
1
103
Kit #14
HEXALOBULAR SOCKET PAN HEAD SCREW
6
104
Kit #16
JACKET, CABLE RUBBER
1
105
Kit #16
PANEL SUBASSEMBLY, CONTROL
1
106
Kit #16
CROSS-RECESSED PAN HEAD SCREW
5
107
Kit #15
BUILT-IN ELECTRONIC FUEL PUMP
1
108
Kit #15
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
109
Kit #15
WIRE CLIP
1
110
Kit #13
FUEL TANK INSTALLATION REAR BRACKET
1
112
Kit #19
MOUNTING BRACKET
1
113
Kit #19
REGULATOR, VOLTAGE
1
114
Kit #2, Kit #19
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
5
115
Kit #25
TRIGGER ASSY.
1
116
Kit #20
CONTROL ASSY BASE PLATE, THROTTLE
1
117
Kit #5
HIGH PRESSURE FUEL TUBE SUBASSEMBLY
1
118
805624
ECU WIRING HARNESS
1
119
Kit #12, Kit #19
CABLE TIES
2
120
Kit #1, Kit #4
AIR FILTER HOUSING GASKET
1
121
Kit #1
FILTER ELEMENT SUPPORT PLATE
1
122
Kit #1
PLUG
1
