34Northtstar Explorer VHF Series: 710US, 710EU Operation and Installation Manual
Appendix A - Technical Specifications
Northstar VHF 710 US.EU
GENERAL
Power Supply: 13.6V DC.
Current drain:
Transmit 6 A at 25 W Tx / 1.5A at 1W Tx
Receive Less than 250mA in standby
Useable channels: International, USA, Canada, Weather (country specifi c)
Mode: 16K0G3E (FM) / 16K0G2B (DSC)
PHYSICAL
LCD display (viewing): 26 mm (H) x 46 mm (W)
FSTN 4 x 12 character matrix with big CH digits/icons
Contrast and
Dimming control: Yes
Antenna connector: SO-239 (50 ohm)
Temperature Range: -15ºC to +50ºC
Waterproof: JIS-7
Dimensions: 161(W) x 75(H) x 147(D) mm - without bracket
Weight: 1.29 kg (2.8 lbs) - without microphone
Frequency stability: +/- 10ppm
Frequency control: PLL
GPS/NMEA input: Yes
Comm. port: 4800 baud NMEA
DSC: Yes
FEATURES
Flush Mount kit and
dust cover: Yes
Local/Distant control: Yes
Position polling: Yes
Group Call: Yes
Call logs: Yes - 20 individual and 10 distress
DSC (USCG SC101
and Class D): Yes (VHF 710US, Class D 710EU)
Channel Naming: Yes
Tri watch, Favourite
channel scan, All scan: Yes
User programmable
MMSID: Yes, User MMSID and ATIS (710EU)
MMSID and NAME
directory: Yes - 20 numbers & group
