Nortik Scubi 2 - Parts and Marking Overview; Hull and Stem Elements; Keel Rods; Cross Ribs for Seats

3
1) Parts overview
#1
1x Hull
#2 2x Stem element (bow
and stern = identical)
#3 4x Keel rod
#4 2x Cross ribs for front
seat 1x open (lower
than for rear seat) 1 x
closed (wider than for
rear seat)
#5 2x Cross ribs for back
seat 1x open, 1 x
closed
#6 Packing bag (no pic)
#7 Repair kit (no pic)
#8 Double action pump
(no pic)
2) Marking
All keel rods have little marks
with arrows. Sort the rods in
a way that all arrows point in
the same direction.
The arrow always points in
direction of the bow.
The two keel rods in the
middle positions have
installed „counter clips“ for
the installation of the cross
ribs
#
1
#
2
#
3
#
4
#
5
