3) Assembly
General proceeding: First you assemble the keel rods and the stem and insert them into the
hull. Then mount the cross ribs and at last inflate the sponsons.
First unfold the hull and take
one of the stem elements
(they are identical).
Take the keel rod shown on
the picture (with the arrow
marking positioned in the
front).
Make sure the arrow points
towards the bow.
Slide the keel rod under the
front seat and push it through
the sleeve on the hull before
clipping it to the stem
element.
Push both as far as possible
into the stern.
Bow-Section
sleeve
keel rod
