2.2 PARTIAL POINT PROGRAMMING D }X3X
The Partial Point Programming menu has the following two options:
1=TYPID Type ID - Change the type ID of an annunciator point connected to the INA.
2=NMAP Network Mapping - Change the network zone or FACP mapping of the annunciator point.
Refer to Figure 2.2-1 for a flow chart of the of the Partial Point Programming menu. Detailed information on the Partial Point
Programming menu options is found on the following pages.
Each option under Partial Point Programming prompts the user to enter the address of the annunciator point or network
zone affected. Leading zeros are not required. The addresses assume the following formats:
Annunciator Point Address - AXXPYY Network Node - NYYYZXXX
3 = PPRG
1 = TYPID
(Type I.D.)
2 = NMAP
(Network Mapping)
Select Partial System
Programming
Option 1-2
Figure 2.2-1 Partial Point Programming Menu Flow Chart
Node Zone
Network Node
1 to 240
