6 NOTI•FIRE•NET™ PN 50257:E 7/5/01

• Fiber Optic Cable - MIB-F

• Twisted Pair Wire and Fiber Optic Cable MIB-WF

Each MIB has two communication ports. The MIB-W has two twisted pair wire ports, the MIB-F

has two fiber optic cable ports and the MIB-WF has one twisted pair wire and one fiber optic cable

port.

The NAM-232 provides a physical communication interface from the AFP-200, AFP-300/AFP-

400, AM2020/AFP1010 Analog Fire Panel to the following communication media which connect

nodes together forming a network:

• Twisted Pair Wire NAM-232W

• Fiber Optic Cable NAM-232F

The Serial Interface Board for NOTI•FIRE•NET™ (SIB-NET) connects an AM2020/AFP1010

to the network through a MIB and permits communication between the AM2020/AFP1010 and

other nodes on the network. The SIB-NET supports all of the same functions as the SIB-2048A;

i.e. Annunciator Control System (ACS), printers, and CRTs.

Each AM2020/AFP1010 requires a network node address.

The NRT-NET interface card and the MIB allow the NRT and NCS to communicate with the

network. The NRT-NET interface card plugs directly into a computer expansion slot located on the

NRT and NCS. The MIB, which supports the physical connection to the network, plugs onto the

NRT-NET card to complete the network interface. Each NRT or NCS requires a network node

address.

The Repeaters (RPT) boost data signals between network nodes extending communication

distances. The RPT-W supports twisted pair wire, the RPT-F supports fiber optic cable, and the

RPT-WF supports twisted pair wire and fiber optic cable.

Service Provided

NOTI•FIRE•NET™, when properly configured, is suitable for use as a Protected Premises Fire

Alarm System as defined in the National Fire Protection Association (NFPA) 72 documentation.
