Overall Limitations
8 NOTI•FIRE•NET™ PN 50257:E 7/5/01
Table 2 Twisted Pair Cable Lengths per Cable Segment (1 of 3)
Cable Manufacturer, Part
Number, and Number of Gauges/
Conductors
Manufacturer's Specifications
Data Threshold:
All Nodes And/Or
Repeaters On A
Cable Segment
Permissible Single Twisted Pair Range
(In Feet) For Each Cable Segment
Point-To-Point Bus Configuration
2 Nodes/Repeaters 3 to 7 Nodes/Repeaters
ACE Wire 61401SLL, 14 AWG,
1 Pair Shielded
FPLP,
NEC Article 760
High: 1-1000 1-100
Low: 800-1400 N/A
ATLAS 228-18-1-1STP-2,
18 AWG, 1 Pair Unshielded
Low Cap., FPL, PVC, NEC
Article 760, UL 1424
High: 1-800 1-100
Low: 800-1600 N/A
ATLAS 228-18-1-1TP-2,
18 AWG, 1 Pair Unshielded
Low Cap., FPL, PVC, NEC
Article 760, UL 1424
High: 1-1200 1-100
Low: 1000-3000 N/A
BELDEN 9583, 12 AWG,
1 Pair Shielded
FPLR, NEC Article 760,
UL 1424
High: 1-600 1-100
Low: 600-1200 N/A
BELDEN 9580, 14 AWG,
1 Pair Unshielded
FPLR, NEC Article 760,
UL 1424
High: 1-1400 1-100
Low: 1300-3000 N/A
BELDEN 9581,
14 AWG, 1 Pair Shielded
FPLR, NEC Article 760,
UL 1424
High: 1-600 1-100
Low: 600-1200 N/A
BELDEN 9572,
16 AWG, 1 Pair Unshielded
FPLR, NEC Article 760,
UL 1424
High: 1-1300 1-100
Low: 1200-3000 N/A
BELDEN 9575,
16 AWG, 1 Pair Shielded
FPLR, NEC Article 760,
UL 1424
High: 1-600 1-100
Low: 600-1200 N/A
BICC BM-D64-02,
16 AWG, 1 Pair Shielded
Contact Manufacturer High: 1-1200 1-100
Low: 1000-1600 N/A
BICC BM-D51-23,
16 AWG, 1 Pair Shielded
Contact Manufacturer High: 1-1400 1-100
Low: 1200-2000 N/A
BRAND-REX 93782-01,
16 AWG, 1 Pair Shielded
Contact Manufacturer High: 1-1400 1-100
Low: 1200-2000 N/A
Genesis GJ-854020514,
14 AWG, 1 Pair Shielded
FPLP,
NEC Article 760
High: 1-400 1-100
Low: 400-800 N/A
Genesis 46065004,
16 AWG, 1 Pair Shielded
FPLP,
NEC Article 760
High: 1-500 1-100
Low: 500-1000 N/A
Genesis WG 78188,
18 AWG, 1 Pair Shielded
FPLP,
NEC Article 760
High: 1-500 1-100
Low: 500-1000 N/A
GUARDIAN E2582S,
18 AWG, 1 Pair Shielded
Mid-Cap., FPL, PVC, NEC
Article 760, UL 1424
High: 1-800 1-100
Low: 800-1400 N/A
Cable Manufacturer, Part
Number, and Number of Gauges/
Conductors
Manufacturer's Specifications
Data Threshold:
All Nodes And/Or
Repeaters On A
Cable Segment
Permissible Single Twisted Pair Range
(In Feet) For Each Cable Segment
Point-To-Point Bus Configuration
2 Nodes/Repeaters 3 to 7 Nodes/Repeaters
GUARDIAN E2572S, 18 AWG, 1
Pair Unshielded
Mid Cap., FPL, PVC, NEC
Article 760, UL 1424
High: 1-1200 1-100
Low: 1000-3000 N/A
NORDX/CDT 24572200,
22 AWG, 4 Pair Unshielded
CMR High: 1-1800 1-100
Low: 1400-2400 N/A
NORDX/CDT 24570036,
24 AWG, 4 Pair Unshielded
CMR High: 1-1400 1-100
Low: 1200-2000 N/A
NYC Fire Cable 51602SLL,
16 AWG, 1 Pair Shielded
Contact Manufacturer High: 1-800 1-100
Low: 800-1000 N/A
REMEE Products,
NY5145HHIRHPHB, 14 AWG, 1
Pair Shielded
FPLP,
NEC Article 760
High: 1-1000 1-100
Low: 800-1400 N/A
SIGNAL 84743-06-14, 18 AWG, 1
Pair Shielded
Mid-Cap., FPLP, PVC, NEC
Article 760, UL 1424
High: 1-600 1-100
Low: 600-1200 N/A
SIGNAL 98281-06-04, 18 AWG, 1
Pair Shielded
Mid-Cap., FPL, PVC, NEC
Article 760, UL 1424
High: 1-600 1-100
Low: 600-1200 N/A
