Nova TITAN User Manual

SuperNova2 – Reassembly
STEPS DESCRIPTION IMAGE
1.
Before reassembling the chuck, apply
a generous amount of lubricant to all
surfaces that come in contact with
other parts.
We recommend applying the lubricant
(before assembly) on the inner
surface of the chuck body as well as
the jaw slide slots . Be sure to apply
lubricant on spiral teeth side.
2.
Reinsert the jaw slides back into their
original slots.
NOTE: The jaw slide number should
be counting up from 1~4 in the
clockwise direction (looking from
front)
3.
Flip the chuck on its face and position
the jaw slides to form a square in the
centre as shown.
Continues to next page…
p.16
