MODEL
System Type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
Coverage Pattern:
HF Horn:
Crossover Modes:
Crossover Frequency:
Power Rating
(Continuous** / Program):
Maximum SPL***:
System Sensitivity (1w/1m):
LF Driver
LF Nominal Impedance:
MF Driver:
MF Nominal Impedance:
HF Driver:
HF Nominal Impedance:
Active Tunings:
Enclosure:
Suspension / Mounting:
Transport:
Finish:
Grille:
Input / Output Connectors:
Dimensions (W x H x D):
Net Weight:
Optional Accessories:
U12A
Digital active 12", two-way,
bass-reflex, stage-monitor / utility
50 Hz - 20 kHz
60 Hz - 18 kHz
60° x 40° nominal
Rotatable horn
Active, internal DSP
1.35 kHz
Bi-Amped LF/MF: 800 W / 1.600 W (@ 8 ohms)
Bi-Amped HF: 300 W / 600 W (@ 8 ohms)
130 dB SPL peak
100 dB SPL
1 x NOVA 12/500EL-8 (3 in. voice coil)
8 ohms (active)
n/a
n/a
1 x BEYMA© TPM4-2500-8, 1.4 in. comp. driver
8 ohms (active)
Internal 32-Bit 3-channel DSP, variable at AUX output
Fullrange, 15 mm, plywood (multi layer)
35 mm pole socket, 5 x ANCRA (comp.), 5 x M8 rigging point
2 x integrated handles
Black NOVA PolyCoat© finish
Magnetic, powder coated, black, perforated steel with acoustic
transparent charcoal foam backing, NOVA logo
350 mm x 590 mm x 324 mm
23.5 kg
FP1: Flexible tilt / pitch (Article number: # 80035)
NFS2: Mounting eyelet (Article number: # 30051)
NFS3: Mounting eyelet (Article number: # 92996)
UMB12: U-bracket for U12A/U12 (Article number: # 30034)
UTA1: Adapter for truss clambs (Article number: # 30036)
UB12: Safety cover for U12A/U12 (Article number: # 30037)
U15A
Digital active 15", two-way,
bass-reflex, stage-monitor / utility
40 Hz - 20 kHz
50 Hz - 18 kHz
60° x 40° nominal
Rotatable horn
Active, internal DSP
1.35 kHz
Bi-Amped LF/MF: 800 W / 1.600 W (@ 8 ohms)
Bi-Amped HF: 300 W / 600 W (@ 8 ohms)
131 dB SPL peak
101 dB SPL
1 x NOVA 15/600EL-8 (3 in. voice coil)
8 ohms (active)
n/a
n/a
1 x BEYMA© TPM4-2500-8, 1.4 in. comp. driver
8 ohms (active)
Internal 32-Bit 3-channel DSP, variable at AUX output
Fullrange, 15 mm, plywood (multi layer)
35 mm pole socket, 5 x ANCRA (comp.), 5 x M8 rigging point
2 x integrated handles
Black NOVA PolyCoat© finish
Magnetic, powder coated, black, perforated steel with acoustic
transparent charcoal foam backing, NOVA logo
410 mm x 650 mm x 364 mm
26.5 kg
FP1: Flexible tilt / pitch (Article number: # 80035)
NFS2: Mounting eyelet (Article number: # 30051)
NFS3: Mounting eyelet (Article number: # 92996)
UMB15: U-bracket for U15A/U15 (Article number: # 30035)
UTA1: Adapter for truss clambs (Article number: # 30036)
UB15: Safety cover for U15A/U15 (Article number: # 30038)
29
MODEL
System Type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
Coverage Pattern:
HF Horn:
Crossover Modes:
Crossover Frequency:
Power Rating
(Continuous** / Program):
Maximum SPL***:
System Sensitivity (1w/1m):
LF Driver
LF Nominal Impedance:
MF Driver:
MF Nominal Impedance:
HF Driver:
HF Nominal Impedance:
Active Tunings:
Enclosure:
Suspension / Mounting:
Transport:
Finish:
Grille:
Input / Output Connectors:
Dimensions (W x H x D):
Net Weight:
Optional Accessories:
U12
12", two-way, bass-reflex, stage-monitor / utility
50 Hz - 20 kHz
60 Hz - 18 kHz
60° x 40° nominal
Rotatable horn
Passive
1.35 kHz
Passive: 600 W / 1.200 W
130 dB SPL peak
100 dB SPL
1 x NOVA 12/500EL-8 (3 in. voice coil)
8 ohms
n/a
n/a
1 x BEYMA© TPM4-2500-8, 1.4 in. comp. driver
8 ohms (active)
n/a (passive)
Fullrange, 15 mm, plywood (multi layer)
35 mm pole socket, 5 x ANCRA (comp.), 5 x M8 rigging point
2 x integrated handles
Black NOVA PolyCoat© finish
Magnetic, powder coated, black, perforated steel with acoustic
transparent charcoal foam backing, NOVA logo
2 x Neutrik© Speakon© NL4
1+/1- (2+/2- linked from input to output)
350 mm x 590 mm x 324 mm
21 kg
FP1: Flexible tilt / pitch (Article number: # 80035)
NFS2: Mounting eyelet (Article number: # 30051)
NFS3: Mounting eyelet (Article number: # 92996)
UMB12: U-bracket for U12A/U12 (Article number: # 30034)
UTA1: Adapter for truss clambs (Article number: # 30036)
UB12: Safety cover for U12A/U12 (Article number: # 30037)
U15
15", two-way, bass-reflex, stage-monitor / utility
40 Hz - 20 kHz
50 Hz - 18 kHz
60° x 40° nominal
Rotatable horn
Passive
1.35 kHz
Passive: 600 W / 1.200 W
131 dB SPL peak
101 dB SPL
1 x NOVA 15/600EL-8 (3 in. voice coil)
8 ohms
n/a
n/a
1 x BEYMA© TPM4-2500-8, 1.4 in. comp. driver
8 ohms
n/a (passive)
Fullrange, 15 mm, plywood (multi layer)
35 mm pole socket, 5 x ANCRA (comp.), 5 x M8 rigging point
2 x integrated handles
Black NOVA PolyCoat© finish
Magnetic, powder coated, black, perforated steel with acoustic
transparent charcoal foam backing, NOVA logo
2 x Neutrik© Speakon© NL4
1+/1- (2+/2- linked from input to output)
410 mm x 650 mm x 364 mm
24 kg
FP1: Flexible tilt / pitch (Article number: # 80035)
NFS2: Mounting eyelet (Article number: # 30051)
NFS3: Mounting eyelet (Article number: # 92996)
UMB15: U-bracket for U15A/U15 (Article number: # 30035)
UTA1: Adapter for truss clambs (Article number: # 30036)
UB15: Safety cover for U15A/U15 (Article number: # 30038)
28
10. Technical Data
Technische Daten
INPUT: 1 x Neutrik© XLR Female
OUTPUTS: 1 x NEUTRIK© XLR Male (LINK from INPUT), 1 x NEUTRIK© XLR Male (AUX from 3. DSP-channel), 1 x USB connector
POWER: 1 x NEUTRIK© PowerCon Input, 1 x NEUTRIK© PowerCon Output (LINK)
