Novamatic TK 660 E - Door Reversal; Connecting a Drain Hose

27
Connecting a
drain hose
If there is a sink or
drain near the
appliance, the
condensed water
can be discharged
directly through a
hose that is
available on the
market.
In order to connect
the hose to the
appliance proceed
as follows:
• Remove the clamp
(A);
• Pull out the plug
(B);
• Insert the drain
hose (C);
• Fasten the hose
(C) to the
appliance using
the clamp (A).
If the appliance is
stacked on the
washing machine,
the condensed
water can be
discharged through
the hose C as
shown in figure, but
take into account
that the hose must
be pointed
downwards.
A
B
A
B
C
P1160
P1161
C
Door reversal
To make it easier to
load or unload the
laundry the door can
be reversed.
This operation
must be carried
out by qualified
personnel.
Please contact the
nearest Service
