now! DRIVE - Binding Mounting Configuration; 4-Hole Pattern Setup; EST;Channel Setup; 3-Hole Pattern Setup

Opening the Foot Pillow
To open your Foot Pillow, grab the soft EVA pad at the heel and
pull upward. Carefully read the instructions provided on the disc
cover before mounting your bindings onto your board.
Hole Patterns and EST Configuration
IMPORTANT: Note the direction that the arrows are pointing on
the washers.
4-HOLE
PATTERN
Arrows on
washers must
point towards
the squares.
3-HOLE PATTERN:
Arrows on washers must point towards the triangles.
EST/CHANNEL
No washers needed.
