Circuit diagram
Installation procedures
RECEIVER
MOTOR
RED
BLACK
RED RED
PINK PINK
GRAY GRAY
L
N
YELLOW/GLEEN
YELLOW/GLEEN
BLUE
WHITE
BLUE
WHITE
7
ALL PICTURES SHOWN ARE FOR ILLUSTRATION PURPOSES ONLY. THE ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENT.
Leave a 3mm to 5mm gap
between the ceiling and the canopy.
Step 7 - Tighten the canopy with the screw provided. Leave a gap of 3mm - 5mm
between the canopy and the ceiling.
