General Venting │ FTV I&O Manual
20
Roof Venting Options – Direct Vent Installation
Figure 4-5 (a) Two-pipe Termination (Roof)
Figure 4-5 (b) Two-pipe Termination (Roof/Sidewall)
Figure 4-5 (c) Concentric Termination (Roof)
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
Exhaust
Inlet
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
Exhaust
Inlet
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
