NuAire EcoSmart Connect Control User Manual

8
15. 02. 22. Document Number 672040
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
BPS H-CO
Installation Manual
1.36 BACnet Object List (By Category)
LCD Page
Number
Object Name Description Point
Type
Instance
Number
Default
Value
Range
1 Baud Rate Baud rate MSV 28508 Auto Auto / 1200 / 9600
/ 19200 / 38400 /
76800
1 Unit Selection Unit Type - State 0 (XBC) / State 1 (BPS) /
State 2 (BOXER)
MSV 28509 State 0 State 0 / State 1 /
State 2
1 Heating Type Selection of Heating Type - State 0 (None) /
State 1 (LPHW) / State 2 (Electric Heater) /
State 3 (3rd Party)
MSV 28510 State 0 State 0 / State 1 /
State 2 / State 3
2 Cooling Type Selection of Cooling Type - State 0 (None) /
State 1 (Chilled Water) / State 2 (3rd Party) /
State 3 (Reverse Cycle DX)
MSV 28511 State 0 State 0 / State 1 /
State 2 / State 3
2 Unit Enable Enable the Unit MSV 28512 Off Off / On
2 Unit Fault Status Fault Relay (Output OUT9) MSV 28539 Normal Alarm / Normal / Hold
2 RM199 Status Status of Network Sensor 1 MSV 28540 FALSE False / True / Hold
3 Alarm Circuit 1 Alarm Circuit 1 MSV 28523 Normal Alarm / Normal / Hold
3 Alarm Circuit 2 Alarm Circuit 2 MSV 28524 Normal Alarm / Normal / Hold
3 SL Input SL Enable (Input IN5) MSV 28525 Off Off / On / Hold
3 Cooling Demand Cooling Demand Status MSV 28538 Off Off / On / Hold
4 SL2 Input SL2 Enable (Input IN6) MSV 28526 Off Off / On / Hold
4 Bypass Damper Bypass damper Status (Output OUT6) MSV 28535 Inactive Inactive / Active / Hold
4 Heat Demand Heat / Recirc Demand (Output OUT8) MSV 28536 Off Off / On / Hold
4 Fan Command Fan Enable Command (Output OUT10) MSV 28537 On Off / On / Hold
5 RM200 Status Status of Network Sensor 2 MSV 28547 FALSE False / True / Hold
5 RM201 Status Status of Network Sensor 3 MSV 28554 FALSE False / True / Hold
5 RM202 Status Status of Network Sensor 4 MSV 28561 FALSE False / True / Hold
5 RM203 Status Status of Network Sensor 5 MSV 28568 FALSE False / True / Hold
6 RM204 Status Status of Network Sensor 6 MSV 28575 FALSE False / True / Hold
6 RM205 Status Status of Network Sensor 7 MSV 28582 FALSE False / True / Hold
6 0-10v Press Range for
IN16 & IN17
0-10v Pressure Range Select for IN16 & IN17
- State 0 (0-25) / State 1 (0-50) / State 2
(0-100) / State 3 (0-300) / State 4 (0-500) /
State 5 (0-1000) / State 6 (0-1600) / State 7
(0-2500) / State 8 (0-3000)
MSV 28599 State 0 State 0 / State 1 /
State 2 / State 3 /
State 4 / State 5 /
State 6 / State 7 /
State 8
6 0-10v CO2 Range for
IN16 & IN17
0-10v CO2 Range Select for IN16 & IN17 -
State 0 (0-2000) / State 1 (0-4000) / State
2 (0-5000) / State 3 (0-10000) / State 4
(0-20000)
MSV 28600 State 0 State 0 / State 1 /
State 2 / State 3 /
State 4
6 IN16 is Temperature Is IN16 setup as = MSV 28601 FALSE False / True / Hold
6 IN16 is Humidity Is IN16 setup as = MSV 28602 FALSE False / True / Hold
6 IN16 is CO2 Is IN16 setup as = MSV 28603 FALSE False / True / Hold
6 IN16 is Pressure Is IN16 setup as = MSV 28604 FALSE False / True / Hold
6 IN17 is Temperature Is IN17 setup as = MSV 28605 FALSE False / True / Hold
6 IN17 is Humidity Is IN17 setup as = MSV 28606 FALSE False / True / Hold
6 IN17 is CO2 Is IN17 setup as = MSV 28607 FALSE False / True / Hold
6 IN17 is Pressure Is IN17 setup as = MSV 28608 FALSE False / True / Hold
6 RM199 Fan Speed
Request
RM199 Fan Speed AV 28545 Current 0, Auto / 1, Off / 2,
Low / 3, Medium / 4,
High
