BOX CONTENTS
CDN22 MK5 CD player transport unit
CDN22 MK5 CD player control unit
Power cord
RCA cables (2 pair)
Control cable
Relay start cable
Quickstart Guide
Safety & Warranty Information Booklet
REGISTRATION
Please go to http://www.numark.com to register your CDN22 MK5. Registering your product ensures that we can keep you
up-to-date with all the latest product developments and provide you with world-class technical support, should you run into any
problems.
GROUND RULES
1. Make sure all items listed in the BOX CONTENTS section are included in the box.
2. READ SAFETY & WARRANTY INFORMATION BOOKLET BEFORE USING THE PRODUCT.
3. Study the connection diagram in this guide.
4. Place mixer in an appropriate position for operation.
5. Make sure all devices are turned off and all faders and gain knobs are set to “zero.”
6. Connect all stereo input sources as indicated in the diagram.
7. Connect the stereo outputs to power amplifier(s), tape decks, and/or other audio sources.
8. Plug all devices into AC power.
9. Switch everything on in the following order:
• Audio input sources (i.e. turntables, CD players, etc.)
• Mixer
• Last, any amplifiers or output devices
10. When turning off, always reverse this operation by:
• Turning off amplifiers
• Mixer
• Last, any input devices
CONNECTION DIAGRAM
RCA CABLE
HOUSE AMP
MONITORS
RCA CABLE
CONTROL
CABLE
FADER START
CABLES
POWER
POWER
MIXER
CONTROL
TRANSPORT
