PAGE 7 SPECIFICATIONS
SPECIFICATIONS
Inputs:
Line: 18K ohm input impedance
200mV rms sensitivity for
4V output
Mic: 3K ohm input impedance
unbalanced
2mV rms sensitivity for 4V output
20mV rms max input
Phono: 47K ohm input impedance
3mV rms sensitivity @ 1KHz for
4V output
Outputs:
Master: 8V rms max
Headphone: 125mW into 32 ohm
Distortion: less than 0.1%
S/N Ratio: (maximum output) JIS-A weighted
Line: Better than -90dB
Mic: Better than -59dB
Phono: Better than -65dB
Frequency response:
Line: 20Hz-20KHz +/-3dB
Mic: 20Hz-20KHz +/-3, -1/-7dB
Phono: +/-3dB except for controlled
attenuation of -10dB @ 10Hz to
reduce rumble and feedback
Channel equalizer:
Bass: +12/-18 ±3dB @100Hz
Treble: +13/-21.5 ±3dB@10KHz
Power consumption:
5Watttypical
8 Watt with full headphone output
General:
Dimensions: 197mm(W) by 267.5mm(D) by 100mm(H)
Weight: 2.4kgs (incl. Transformer)
