Numark iDJ3 Service Manual

...3
TE962541401 14P CONNECTOR
1
(J8)
...3
TE962542001 20P CONNECTOR
1
(J7)
...3
TR2SK1828 MOSFET N-CH 20V MAIN 2-Pin
4
Q7~10
...3
VRR10301704 Poltertiomaeter Rotary Volume 10K2B
3
P1~3
...3
VRR10317502 Potentiometer Rotary Volume 10K15Ax2
2
P4,5
...3
VRS10304518 Potentiometer Slide 10K
1
P9
...3
VRS10304521 POTENTIOMETER SLIDE VOLUME 10KA*2
1
R4
...3
XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental
1
X1
..2
TWPC10C003B01 VR PCB ASS'Y
1 22
...3
AL0-09-0057 VR 10KB
1
R2
...3
AL3-02-0036 YELLOW LED
1
D20
...3
BALE42207-5A LED HOLDER
1
(D20)
...3
CS104K5003X7R CERAMIC 0.1uF/50V 10% 0603 X7R
7
C36,38,39,42,44~46
...3
DIEN1N4148WSM DIODE SMD
11
D47~55,61,62
...3
FCN1T1003001 FCN Down Touch 90° Pitch 1.0mm 30P
1
J3
...3
IC74LVC574APWR IC SN74LVC574APWR
1
U13
...3
LD-L169XSYDK Liquid-emitting Diode Amber Rectangular
9
D21~29
...3
PT01104803 LED Fixed 4.8X3mm
9
(D21~29)
...3
RS018010F03 RESISTOR 180 1% SMD 0603
1
R118
...3
RS022010F03 RESISTOR 220 1% SMD 0603
6
R113~116,119,120
...3
RS027010F03 RESISTOR 270 1% SMD 0603
1
R117
...3
SWEVQ11L05R Switch Tact
11
SW23~33
...3
VRR10301704 Poltertiomaeter Rotary Volume 10K2B
3
P6~8
..2
TWPC10C003C01 SW PCB ASS'Y
1 25
...3
BALE48201-5A LED Fixed 1.5MM
1
(D17)
...3
FCN1R1001605 FCN UP Touch smd Pitch 1.0mm 16Pin have latch
1
J2
...3
LD-L169XCGDK Liquid-emitting Diode Green Rectangular
2
D13,14
...3
LD-L169XSRD Liquid-emitting Diode Red Rectangular
1
D15
...3
LD-L169XSYDK Liquid-emitting Diode Amber Rectangular
2
D16,17
...3
PT01104803 LED Fixed 4.8X3mm
4
(D13~16)
...3
SWEVQ11L05R Switch Tact
5
SW14~17,20
0.1
TWPC10C00401 DOCK PCB ASS'Y
1 54
..2
AL2-54-0138 MOSFET BSS138 N-CH SOT-23
2
Q1,2
..2
JKMF1514S0117 IPOD Connector
1
J1
..2
PC10C004 DOCK PCB
1
-
..2
RS000010J03 RESISTOR 0 5% SMD 0603
2
R8,9
..2
RS001K10F03 RESISTOR 1K 1% SMD 0603
1
R1
..2
RS010010F03 RESISTOR 100 1% SMD 0603
1
R2
..2
RS075K10F03 RESISTOR 75K 1% SMD 0603
2
R4,5
..2
RS100K10F03 RESISTOR 100K 1% SMD 0603
2
R10,11
..2
RS49K910F03 RESISTOR 49.9K 1% SMD 0603
2
R6,7
..2
RS549K10F03 RESISTOR 549K 1% SMD 0603
1
R3
..2
TE10200502 5P CONNECTOR
1
(J3)
..2
TE10200601 6P CONNECTOR
1
(J2)
..2
TE612000801 8P CONNECTOR
1
(J5)

Numark iDJ3 Specifications

General

Mixer section	Yes
Product color	Black, Silver
Scratcher type	Digital Vinyl System (DVS) scratcher
USB direct playback	-
Built-in optical drive	No
Number of mixer channels	3 channels
Number of scratcher platters	2
Headphone outputs	1
USB connector type	USB Type-B
Apple docking compatibility	iPhone, iPod
Minimum RAM	0.512 GB
Minimum processor	Pentium 4, AMD Athlon XP
Minimum storage drive space	20 MB
Minimum display resolution requirement	1024 x 768 pixels
Cables included	USB
Bundled software	Virtual DJ LE
