Numark iDJ3 Service Manual

..2
TE622000801 8P CONNECTOR
1
(J3)
..2
TE962541001 10P TERMINAL
1
(J7)
..2
TE962541401 14P CONNECTOR
1
(J1)
..2
TR2SD2114KSM TRANSISTOR 2SD2114K NPN SOT-23
4
Q8~11
..2
UHACM2012900-2P CHOKE 90 0.4A 2.0X1.2mm
1
L1
..2
XTM11289X6F1 Crystal 11.2896MHz 49US SMD Fundamental
1
X1
..2
XTM12288X6F1 Crystal 12.288MHZ 49US SMD Fundamental
1
X2
..2
XTM16000X6 Crystal 16MHZ 49US SMD Fundamental
1
X3
0.1
TWPC10C00301 MAIN PCB ASS'Y
1
..2
PC10C003 MAIN PCB
1
..2
TWPC10C003A01 MAIN PCB ASS'Y
1 26
...3
AL0-09-0057 VR 10KB
3
R1,3,5
...3
AL0-17-0103 RESISTOR ARRAY 4X10K 1/10W 0603
2
R6,14
...3
AL2-50-4149 Diode Signl 1N4148 100V 200mA SOT-23
4
D43~46
...3
AL2-51-4401 TRANSISTOR 2N4401
14
Q1~6,11~18
...3
AL2-73-4051 IC 74HC4051
2
U2,3
...3
AL3-02-0036 YELLOW LED
1
D10
...3
BALE42207-5A LED HOLDER
1
(D10)
...3
BALE48201-5A LED Fixed 1.5MM
5
(D11,12,18,19,30)
...3
CN0100001007 Flat Cable GND Wire Length 100mm
2
TP2,3
...3
CS102K5003X7R CERAMIC 1nF/50V 10% 0603 X7R
2
C24,25
...3
CS103K5003X7R CERAMIC 0.01uF/50V 10% 0603 X7R
1
C20
...3
CS104K5003X7R CERAMIC 0.1uF/50V 10% 0603 X7R
26
C7~13,17~19,22,23,26,27,29~32,35,37,40,41,43,47~49
...3
CS180J5003NPO CERAMIC 18pF/50V 5% 0603 NPO
4
C14,15,33,34
...3
CS475K1006X5R CERAMIC 4.7uF/10V 10% 1206 X5R
3
C16,21,28
...3
DIEN1N4148WSM DIODE SMD
13
D35~42,56~60
...3
DIRPI-352 SENSOR
4
SEN1~4
...3
EC22616TS Capacitor Electrolytic 22uF/16V 5*5mm
6
C1~6
...3
FCN1R1001605 FCN UP Touch smd Pitch 1.0mm 16Pin have latch
1
J2
...3
FCN1T1003001 FCN Down Touch 90° Pitch 1.0mm 30P
1
J1
...3
IC2-77-0103 IC Touch (2-77-0103)
1
U10
...3
IC74LVC574APWR IC SN74LVC574APWR
3
U6,12,15
...3
ICMFI341S2164 IC MFI341S2164
1
U1
...3
ICSN74HC14D IC SN74HC14D
2
U8,9
...3
ICYH99C01 IC YH99C01 (STM32F102R8T6+PROGRAM)
1
U4
....4
ICSTM32F102R8T6 IC STM32F102R8T6
1
-
...3
LD-L169XCGDK Liquid-emitting Diode Green Rectangular
2
D33,34
...3
LD-L169XSRD Liquid-emitting Diode Red Rectangular
1
D32
...3
LD-L169XSYDK Liquid-emitting Diode Amber Rectangular
15
D1~9,11,12,18,19,30,31
...3
MT070446701 IRON PLATE
1
(ENC1)
...3
PT01104803 LED Fixed 4.8X3mm
13
(D1~9,31~34)
...3 RS000010J03 RESISTOR 0 5% SMD 0603 34
R49~51,58~69,72~74,76,77,121,122,124,126,128,130,
132,134,136,138~140,142,143
...3
RS000110J03 RESISTOR 1 5% SMD 0603
1
R35
...3
RS001K10F03 RESISTOR 1K 1% SMD 0603
6
R70,71,90,92,94,100
...3
RS001M10F03 RESISTOR 1M 1% SMD 0603
2
R15,16
...3
RS010010F03 RESISTOR 100 1% SMD 0603
21
R10~12,17,18,24,27~34,36,37,39~43
...3
RS010K10F03 RESISTOR 10K 1% SMD 0603
16
R7~9,13,38,46~48,83,85,89,91,93,96,97,106
...3
RS018010F03 RESISTOR 180 1% SMD 0603
1
R109
...3
RS022010F03 RESISTOR 220 1% SMD 0603
19
R19~22,26,52~57,112,123,125,127,129,133,135,137
...3
RS022K10F03 RESISTOR 22K 1% SMD 0603
4
R80,87,95,104
...3
RS027010F03 RESISTOR 270 1% SMD 0603
7
R99,103,105,108,110,111,131
...3
RS033010F03 RESISTOR 330 1% SMD 0603
4
R82,84,98,101
...3
RS04K710F03 RESISTOR 4.7K 1% SMD 0603
4
R23,25,44,45
...3
RS056010F03 RESISTOR 560 1% SMD 0603
4
R86,88,102,107
...3
RS100K10F03 RESISTOR 100K 1% SMD 0603
2
R75,79
...3
RS270K10F03 RESISTOR 270K 1% SMD 0603
2
R78,81
...3
SWDC11B2021431 SWITCH
1
ENC1
...3
SWEVQ11L05R Switch Tact
22
SW1~13,18,19,21,22,34~38
...3
SWLBC23M-15K SLIDE SWITCH 2P 3T
1
S1
...3
TE10200502 5P CONNECTOR
1
(J6)
...3
TE612001201 12P CONNECTOR
1
(J5)
...3
TE962541001 10P CONNECTOR
1
(J9)

Numark iDJ3 Specifications

General

Mixer section	Yes
Product color	Black, Silver
Scratcher type	Digital Vinyl System (DVS) scratcher
USB direct playback	-
Built-in optical drive	No
Number of mixer channels	3 channels
Number of scratcher platters	2
Headphone outputs	1
USB connector type	USB Type-B
Apple docking compatibility	iPhone, iPod
Minimum RAM	0.512 GB
Minimum processor	Pentium 4, AMD Athlon XP
Minimum storage drive space	20 MB
Minimum display resolution requirement	1024 x 768 pixels
Cables included	USB
Bundled software	Virtual DJ LE
